A-INFO 100MHz-110GHz Broadband Waveguide Horn Antenna

Reference: LB-34-20-C-KF

Brand: A-INFO

Standard Gain Horn Antenna, 22-33GHz 20dB Gain WR34

Frequency Range: 22-33 GHz Waveguide Type: Rectangular Waveguide Size EIA WR: WR34 Gain, Typ: 20 dB Polarization: Linear 3dB Beamwidth, E-Plane, Typ (Deg.) 15 3dB Beamwidth, H-Plane, Typ (Deg.) 17 Cross Pol. Isolation, Typ (dB): 25dB Application: General Purpose Indoor & Outdoor, FixedSolution for: Gain Reference, Antenna Measurement, Reflector Feed,...

Reference: A-INFO Corrugated Feed Horn Antennas

Brand: A-INFO

A-INFO Corrugated Feed Horn Antennas with Waveguide and Coaxial Interface, Dual Linear Polarization, Equipped with Absorber

LB-ACH series corrugated feed horn antennas have features like: rotationally symmetric radiation pattern, low cross polarization and stable amplitude taper within operating frequency. There are four kinds of polarization options: Linear, Circular(RHCP/LHCP), Dual Linear and Dual Circular for LB-ACH series feed horn antenna. A-INFO's corrugated feed horn...

Reference: Rectangular Waveguide Probes with Right Angle Coaxial Output

Brand: A-INFO

A-INFO 0.32 to 110GHz Rectangular Waveguide Probes with Right Angle Coaxial Output

A-INFO's Open Ended WG Probes have been specifically designed for near-field measurement. The EWG series Open Ended Waveguide Probes are Linear Polarization and are covering the frequency range from 0.32 to 110GHz by using standard WG band. All probes have an option of integration with absorber for better gain flatness and radiation pattern.

Reference: A-INFO Conical Horn Antennas

Brand: A-INFO

A-INFO 5.3GHz to 220GHz Conical Horn with Ortho-Mode Transducer (OMT) - Dual Linear Polarization

The LB-CNH series conical horn antennas have four kinds of polarization options: Linear, Circular(RHCP/LHCP), Dual Linear and Dual Circular. And YLB series conical horn antennas are Linear Polarization. A-INFO's conical horn antenna can cover from 5.3GHz to 220GHz frequency range. Those conical horns are precisely fabricated to minimize the tolerance of...

Reference: A-INFO Multi Octave Horn Antennas

Brand: A-INFO

A-INFO 840MHz to 40GHz Multi Octave Horn Antennas

The LB series multi octave horn antennas are linearly polarized and provide an efficient low cost means of making broadband measurements. A-INFO's horn antenna can cover from 840MHz to 40GHz frequency range. These horns are ideally suited for EMI testing, direction finding, surveillance, antenna gain and pattern measurements and other applications. The LB...

Reference: A-INFO Broadband Dual Polarization Horn Antenna

Brand: A-INFO

A-INFO 1GHz-67GHz Broadband Dual Polarization Horn Antenna

Reference: A-INFO Lens Horn Antennas

Brand: A-INFO

A-INFO Lens Horn Antenna

Models up to 112GHz   Linear, dual and circular polarization Optional protective membrane   Rectangular or circular feed Ideally suited for small and large quantities   Choice of mounting configurations Customization available   Choice of waveguide to coaxial adapter

Reference: LB-CH-28-20-T26

Brand: A-INFO

5G Measurements, 23.5-43.5GHz 20dB Gain, Dual Linear Polarization Corrugated Conical Horn Antenna

Applications: > 5G Applications and Systems  > Millimeter Wave Test  > Near Field, Far Field, CATR, and OTA  > Short Distance Wireless Communication  > UWB Communication Systems  > Radar Systems  > Other Applications

Reference: A-INFO Dual Polarization Waveguide Probes

Brand: A-INFO

A-INFO 2.6 to 220GHz Dual Polarization Waveguide Probes with V Port Endlaunch Coaxial Interface, Equipped with Absorber

A-INFO's Dual Polarization WG Probes have been specifically designed for near-field measurement. The EWG series Dual Polarization Waveguide Probes are dual Polarization and are covering the frequency range from 2.6 to 220GHz by using standard WG band. All probes have an option of integration with absorber for better gain flatness and radiation pattern.

Reference: A-INFO Conical Horn Antennas

Brand: A-INFO

A-INFO 5.3GHz to 220GHz Conical Horn with Polarizer and Ortho-Mode Transducer (OMT) - Dual Circular Polarization

The LB-CNH series conical horn antennas have four kinds of polarization options: Linear, Circular(RHCP/LHCP), Dual Linear and Dual Circular. And YLB series conical horn antennas are Linear Polarization. A-INFO's conical horn antenna can cover from 5.3GHz to 220GHz frequency range. Those conical horns are precisely fabricated to minimize the tolerance of...

Reference: A-INFO Rectangular Waveguide Probes with Waveguide Interface

Brand: A-INFO

A-INFO 0.32 to 110GHz Rectangular Waveguide Probes with Waveguide Interface, Equipped with Absorber

A-INFO's Open Ended WG Probes have been specifically designed for near-field measurement. The EWG series Open Ended Waveguide Probes are Linear Polarization and are covering the frequency range from 0.32 to 110GHz by using standard WG band. All probes have an option of integration with absorber for better gain flatness and radiation pattern.

Reference: A-INFO Gaussian Optical Lens Horn Antennas

Brand: A-INFO

A-INFO Gaussian Optical Lens with Conical Horn Feed

GL and GLC series Gaussian optical lens horn antenna are especially useful when high gain is required with the minimum size. They are composed by feed and lens in order to apply phase correction and achieve superior performance with minimum size. The antenna  employs a corrugated or conical feed horn to offer excellent aperture efficiency, high cross...

Reference: A-INFO Conical Horn Antennas

Brand: A-INFO

A-INFO 5.3GHz to 220GHz Conical Horn with Integrated Rectangular WG Transition - Linear Polarization

The LB-CNH series conical horn antennas have four kinds of polarization options: Linear, Circular(RHCP/LHCP), Dual Linear and Dual Circular. And YLB series conical horn antennas are Linear Polarization. A-INFO's conical horn antenna can cover from 5.3GHz to 220GHz frequency range. Those conical horns are precisely fabricated to minimize the tolerance of...

Reference: A-INFO Conical Horn Antennas

Brand: A-INFO

A-INFO 5.3GHz to 220GHz Conical Horn with Rectangular WG Transition - Linear Polarization

The LB-CNH series conical horn antennas have four kinds of polarization options: Linear, Circular(RHCP/LHCP), Dual Linear and Dual Circular. And YLB series conical horn antennas are Linear Polarization. A-INFO's conical horn antenna can cover from 5.3GHz to 220GHz frequency range. Those conical horns are precisely fabricated to minimize the tolerance of...

Reference: A-INFO Corrugated Feed Horn Antennas

Brand: A-INFO

A-INFO 0.75GHz to 220GHz Corrugated Feed Horn Antennas with Waveguide and Coaxial Interface, Equipped with Absorber

LB-ACH series corrugated feed horn antennas have features like: rotationally symmetric radiation pattern, low cross polarization and stable amplitude taper within operating frequency. There are four kinds of polarization options: Linear, Circular(RHCP/LHCP), Dual Linear and Dual Circular for LB-ACH series feed horn antenna. A-INFO's corrugated feed horn...

Reference: LB-660

Brand: A-INFO

Broadband Horn Antenna, 0.6-6.0 GHz 11dB Gain, N Type Female

Frequency Range :     0.6-6 GHz Gain, Typ:                 11 dB Polarization:              Linear 3dB Beamwidth, E-Plane, Range (Deg.) 33 - 92 3dB Beamwidth, H-Plane, Range (Deg.) 34-56 Cross Pol. Isolation, Typ (dB) : 25 Application: General Purpose Indoor & Outdoor, FixedSolution for: Gain Reference, Antenna Measurement, Reflector Feed, Far-field...
