| Thermal Imaging |
|---|
| Detector Type |
Uncooled infrared detector
|
|---|
| Infrared Resolution |
256×192
|
|---|
| Pixel Size |
12μm
|
|---|
| Spectral Band |
7.5-14μm
|
|---|
| Thermal Sensitivity (NETD) |
＜40mK (25°C,F1.0)
|
|---|
| Frame Rate |
25Hz
|
|---|
| Lens Focal Length |
3.2mm
|
|---|
| FOV |
56°×42°
|
|---|
| Spatial Resolution (IFOV) |
3.75mrad
|
|---|
| Focusing Mode |
Fixed focus
|
|---|
| Minimum Imaging Distance |
0.3m
|
|---|
| Measurement Range |
-20°C~+150°C, 100°C~550°C
|
|---|
| Measurement Accuracy |
±2°C or ±2% of readings, whichever is greater
|
|---|
|
| Imaging Display |
|---|
| Display |
2.8 inch, 320×240
|
|---|
| Visible Light Camera |
2 megapixels
|
|---|
| Digital Zoom |
1× 2× 4×
|
|---|
| Palettes |
7
|
|---|
| Image Mode |
Infrared, visible light, PIP, dual-spectrum fusion
|
|---|
| Temperature Width Stretch |
Auto
|
|---|
|
| Measurement and Analysis |
|---|
| Analysis Functions on the Device |
Central temperature point/Highest temperature point/Lowest temperature point
|
|---|
| Supporting Software |
PC (Infrared Analysis Software)
|
|---|
|
| Image Storage |
|---|
| Storage Medium |
Standard 32GB MicroSD, up to 128G
|
|---|
|
| System Functions |
|---|
| Alarm Type |
Highest/Lowest temperature alarm in full frame; Image pop-ups, flash prompts; Auto image capture at alarm time (with temperature data).
|
|---|
| Power Management |
Auto shut-down setting
|
|---|
|
| Others |
|---|
| Battery |
Built-in rechargeable lithium-ion battery
|
|---|
| Battery Life |
About 11h
|
|---|
| Charging Mode |
USB Type-C
|
|---|
| Interface |
USB Type-C, SD card
|
|---|
| Tripod Socket |
UNC 1/4-20 interface for tripod
|
|---|
| Operating Temperature |
-10°C~+50°C
|
|---|
| Operating Humidity |
10%~95% (non-condensing)
|
|---|
| Storage Temperature |
-20°C~+60°C
|
|---|
| Ingress Protection Rating |
IP54
|
|---|
| Shock and Vibration |
Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
|
|---|
| Weight and Dimensions |
About 520g, 237×75×92mm
|
|---|
| Authentication |
CE/RoHS/CMA, etc.
|
|---|
| Packing List |
Infrared camera×1, USB cable, 32GB SD card, user manual, storage bag, certificate of qualification, calibration certificate
|
|---|
|
Power Maintenance
HVAC Leak Detection
Equipment Inspection
Automotive Maintenance
