| Thermal Imaging |
|---|
| Detector Type |
Uncooled infrared detector
|
|---|
| Infrared Resolution |
640×512
|
|---|
| Pixel Size |
12μm
|
|---|
| Spectral Band |
7.5-14μm
|
|---|
| Thermal Sensitivity (NETD) |
＜35mK (25°C,F1.0)
|
|---|
| Frame Rate |
30Hz
|
|---|
| Lens Focal Length |
9.1mm
|
|---|
| FOV |
48°×38°
|
|---|
| Spatial Resolution (IFOV) |
1.31mrad
|
|---|
| Focusing Mode |
Manual focusing
|
|---|
| Measurement Range |
-20°C~+150°C, 100°C~550°C
|
|---|
| Measurement Accuracy |
±2°C or ±2% of readings, whichever is greater
|
|---|
|
| Imaging Display |
|---|
| Display |
3.5-inch touch screen, 640×480 resolution
|
|---|
| Visible Light Camera |
5 megapixels
|
|---|
| Digital Zoom |
1×, 2×, 4×, 8×
|
|---|
| Palettes |
10
|
|---|
| Image Mode |
Infrared, visible light, PIP, dual-spectrum fusion
|
|---|
| Temperature Width Stretch |
Automatic/Manual
|
|---|
|
| Measurement and Analysis |
|---|
| Analysis Functions on the Device |
Custom points/lines/areas; up to 10 points, 10 areas, and 10 lines; Center point/Hot and cold spot tracking and temperature display
|
|---|
| Supporting Software |
PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP)
|
|---|
|
| Image Storage |
|---|
| Storage Medium |
Standard 32GB MicroSD, up to 512G
|
|---|
| Text Notes |
Support
|
|---|
| Voice Annotation |
Support
|
|---|
| Image Naming |
Auto/manual naming, naming by scanning QR code
|
|---|
|
| System Functions |
|---|
| Communication Protocol |
Wi-Fi, USB
|
|---|
| Video Transmission |
Support UVC video transmission
|
|---|
| Laser Pointer |
Support
|
|---|
|
| Others |
|---|
| Battery |
Rechargeable and detachable lithium-ion battery
|
|---|
| Battery Life |
About 6h (about 3h for a single battery)
|
|---|
| Charging Mode |
USB Type-C or desktop charger
|
|---|
| Interface |
USB Type-C, SD card
|
|---|
| Tripod Socket |
UNC 1/4-20 interface for tripod
|
|---|
| Operating Temperature |
-10°C~+50°C
|
|---|
| Operating Humidity |
10%~95% (non-condensing)
|
|---|
| Storage Temperature |
-20°C~+60°C
|
|---|
| Ingress Protection Rating |
IP54
|
|---|
| Shock and Vibration |
Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
|
|---|
| Weight and Dimensions |
About 670g, 258.4×105.1×102.3mm
|
|---|
| Authentication |
CE/RoHS/CMA, etc.
|
|---|
| Packing List |
Thermal camera, 5V 3A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, safety box
|
|---|
|
