| Thermal Imaging Parameters |
|---|
| Detector |
Uncooled VOx detector
|
|---|
| Infrared Resolution |
384×288
|
|---|
| Pixel pitch |
17μm
|
|---|
| Spectral Band |
8μm~14μm
|
|---|
| Thermal Sensitivity (NETD) |
<50mK
|
|---|
|
| Temperature Measurement Function |
|---|
| Measurement Range |
-20℃~+150℃,0℃~550℃
|
|---|
| Measurement Accuracy |
±2°C or ±2% of readings, whichever is greater.
|
|---|
| Temperature Measurement Correction |
Reflected temperature, ambient temperature, atmospheric transmissivity, object emissivity, distance
|
|---|
| Measurement Tool |
Settings of measurement rules for a total of 12 points, lines, and areas Supports isotherm setting
|
|---|
| Temperature Width Stretch |
Support temperature width stretch
|
|---|
|
| Image and Video |
|---|
| Frame Rate |
50Hz
|
|---|
| Palettes |
18 color palettes including black-hot, white-hot, iron red, rainbow, etc.
|
|---|
| Video Standards |
H.264, H.265
|
|---|
| Thermal Image Capture |
Support thermal image capture and secondary analysis
|
|---|
| Mirror Image |
Horizontal/Vertical/Diagonal
|
|---|
| Digital Zoom |
1.0~8.0 continuous zoom (step size: 0.1)
|
|---|
|
| System Interface |
|---|
| Communication interface |
RJ45，supporting Gigabit network and customized RS485 for Pecol-D protocol.
|
|---|
| Video Interface |
1-channel analog video
|
|---|
| Alarm Interface |
1-channel alarm output (optional)
|
|---|
| Network Protocol |
TCP, UDP, ICMP, DHCP, RTSP
|
|---|
| Interface Protocol |
ONVIF, GB28181
|
|---|
|
| Device Specifications |
|---|
| Operating Temperature |
-20℃~+60℃
|
|---|
| Power supply mode |
10~36V DC, POE
|
|---|
| Typical Power Consumption |
3W
|
|---|
| Dimensions |
55mm×55mm×110mm
|
|---|
| Weight |
About 430g
|
|---|
|
Education and Research
Industrial Manufacturing
Machine Vision
Power Monitoring
