| Thermal Imaging Parameters |
|---|
| Detector |
Uncooled VOx detector
|
|---|
| Infrared Resolution |
384×288
|
|---|
| Pixel pitch |
12μm
|
|---|
| Spectral Band |
7.5μm~14μm
|
|---|
| Thermal Sensitivity (NETD) |
≤40mK
|
|---|
|
| Temperature Measurement Function |
|---|
| Measurement Range |
-20℃~+150℃, 0~650℃
|
|---|
| Measurement Accuracy |
±2°C or ±2% of readings, whichever is greater.
|
|---|
| Temperature Measurement Correction |
Reflected temperature, ambient temperature, atmospheric transmissivity, object emissivity, distance
|
|---|
| Measurement Tool |
Settings of measurement rules for a total of 12 points, 12 lines, and 12 areas,support isotherm setting
|
|---|
| Temperature Width Stretch |
Support temperature width stretch
|
|---|
|
| Image and Video |
|---|
| Frame Rate |
50Hz
|
|---|
| Palettes |
20 color palettes including black-hot, white-hot, iron red, rainbow, etc.
|
|---|
| Video Standards |
H.264, H.265
|
|---|
| Thermal Image Capture |
Support thermal image capture and secondary analysis
|
|---|
| Mirror Image |
Horizontal/Vertical/Diagonal
|
|---|
| Digital Zoom |
1.0~8.0 continuous zoom (step size: 0.1)
|
|---|
|
| System Interface |
|---|
| Communication interface |
RJ45, supporting Gigabit network.1-channel RS485, supporting Pelco-D protocol expansion (optional).
|
|---|
| Audio Interface |
1-channel audio input, 1-channel audio output
|
|---|
| Video Interface |
1-channel analog video
|
|---|
| Alarm Interface |
1-channel alarm input, 1-channel alarm output
|
|---|
| Storage Interface |
Support TF card
|
|---|
| Network Protocol |
IPv4, HTTP, HTTPS, SMTP, FTP, UPnP, DNS, DDNS, NTP, RTCP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP
|
|---|
| Interface Protocol |
Modbus TCP, ONVIF, GB28181, MQTT
|
|---|
|
| Device Specifications |
|---|
| Operating Temperature |
-40°C~+70℃
|
|---|
| Power supply mode |
9V-15V DC, optional POE power supply
|
|---|
| Typical Power Consumption |
2.4W
|
|---|
| Dimensions |
45mm×44mm×60mm (without lens)
|
|---|
| Weight |
About 110g (without lens)
|
|---|
|
Industrial Manufacturing
Machine Vision
Power Monitoring
Railway Inspection
