64-CH 28GHz mmWave Active Phased Array Antenna
ZMB28-64TRA
AppVision Australia ZMB28-64TRA is TDD mode 64-channel mmWave Active Phased Array Antenna, with PA, LNA and shifter for each channel. Antenna can be controlled by USB port via SCPI command or high-speed digital I/O to do high-speed 3D beam scanning.
The input and output frequency range of ZMB28-64TRAis 27~29GHz which can be integrated with NI PXI mmWave system or other VSA/VSG. It can also be integrated with any system with external LO and mixer.
Product Details
ZMB28-64TRA
AppVision Australia ZMB28-64TRA is TDD mode 64-channel mmWave Active Phased Array Antenna, with PA, LNA and shifter for each channel. Antenna can be controlled by USB port via SCPI command or high-speed digital I/O to do high-speed 3D beam scanning.
The input and output frequency range of ZMB28-64TRAis 27~29GHz which can be integrated with NI PXI mmWave system or other VSA/VSG. It can also be integrated with any system with external LO and mixer.
