Main Features
The dynamic test function allows the load to switch between the two set parameters according to the set rules, thereby testing the dynamic characteristics of the device under test. The SDL1000X can be set to a maximum frequency of 25 kHz in CC dynamic mode. The current probe can track current changes at high speed and analyze current waveforms. In CV mode, the voltage can be quickly and stably set to test the fast output capability of the power supply. If the instantaneous power exceeds the protection set value, it will enter the hiccup protection state.
The Program function can simulate multiple tests such as CC, CV, CR, CP, LED, etc. A total of 10 test files can be edited, and each test file supports up to 50 steps.
The List function supports load-built multi-step, timed, and test environments with different load states. By editing the step values, pulse widths, and slopes of a single step, the load can generate a variety of complex sequence combinations to meet different test needs.
Based on the traditional CR mode, the SDL1000X adds the turn-on voltage setting of the diode, which can simulate the working state of the real diode and measure the chopping current during the LED test.
The battery test function can effectively reflect the reliability and remaining life of the battery. The battery was subjected to a discharge test by setting termination conditions such as termination voltage, discharge capacity, and discharge time using CC, CP, and CR modes.
Reference: M9716
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Battery test and short-circuit test functions Available with RS232/RS485/USB serial interfaces. 2400W 0-150V 0-240A
Reference: M9712C
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Battery test and short-circuit test functions Available with RS232/RS485/USB serial interfaces. 300W 0-150V 0-60A
Reference: SDL1020X-E
Brand: Siglent
Main Features DC 150 V/30 A, maximum total power 200 W Adjustable current rise/fall rate 0.001 A/μs~2.5 A/μs Four static/dynamic modes: CC/CV/CP/CR Readback resolution 1 mV, 1 mA CC Dynamic mode: Continuous, pulsed, toggled CC Dynamic mode: 25 kHz, CP Dynamic mode: 12.5 kHz, CV Dynamic mode: 0.5 Hz Measuring speed of voltage and current: up to 500 kHz...
Reference: AC/DC Source and Load
Brand: BriPower
· Compact modular design, 15KVA in 4U · Bi-directional design · Output: AC, DC, AC+DC · Single unit: maximum 15KW, 450V L-N, 30A/ph, DC-1KHz output · Single phase, 3-phase, split phase, and multi-channel output · Various modes: Regenerative AC/DC source, regenerative AC/DC load, BiPolar DC source · Regenerative RLC load in full frequency range · True...
Reference: M9718B
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Battery test and short-circuit test functions Available with RS232/RS485/USB serial interfaces. 3600W 0-500V 0-120A
Reference: M9714B
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Battery test and short-circuit test functions Available with RS232/RS485/USB serial interfaces. 1200W 0-500V 0-60A
Reference: SDL1020X
Brand: Siglent
Main Features DC 150 V/30 A, maximum total power 200 W Adjustable current rise/fall rate 0.001 A/μs~2.5 A/μs Four static/dynamic modes: CC/CV/CP/CR Readback resolution 0.1 mV, 0.1 mA CC Dynamic mode: Continuous, pulsed, toggled CC Dynamic mode: 25 kHz, CP Dynamic mode: 12.5 kHz, CV Dynamic mode: 0.5 Hz Measuring speed of voltage and current: up to...
Reference: M9715
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Battery test and short-circuit test functions Available with RS232/RS485/USB serial interfaces. 1800W 0-150V 0-240A
Reference: N8361
Brand: NGI
●Voltage Range:0~20V ●Current Range:-10A~+10A ●Single channel power up to 200W ●Voltage rise and fall time ≤50μs ●Current Accuracy up to 1μA ●High precision DVM ●Support front and rear outlet, easier for desktop & integration ●With digital I/O, supporting trigger test ●LAN/RS232/CAN Interface
Reference: M9834
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Over-current, over-voltage, overpower, overheating, and polarity reversal protection Available with RS232/RS485/USB serial interfaces. Supports remote voltage compensation and multi-data storage 10 kW 0-150V 0-500A
Reference: M9718F
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Battery test and short-circuit test functions Available with RS232/RS485/USB serial interfaces. 6000W 0-150V 0-480A
Reference: M9717B
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Battery test and short-circuit test functions Available with RS232/RS485/USB serial interfaces. 3600W 0-500V 0-120A
Reference: M9835
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Over-current, over-voltage, overpower, overheating, and polarity reversal protection Available with RS232/RS485/USB serial interfaces. Supports remote voltage compensation and multi-data storage 15 kW 0-150V 0-500A
Reference: M9713B
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Battery test and short-circuit test functions Available with RS232/RS485/USB serial interfaces. 600W 0-500V 0-30A
Reference: AC/DC Power Source & Load
Brand: BriPower
· Modular design, output power from 15kVA to 1080kVA · Bi-directional AC/DC power source, seamless transition between source and sink modes · Regenerative AC/DC load function · Output: AC, DC, AC+DC · Using true current feedback control when working in CC mode · Frequency Range: DC~ 5kHz · Soft start: effectively restrain the impulse current when power...
Reference: M9718E
Brand: Maynuo
Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CV Battery test and short-circuit test functions Available with RS232/RS485/USB serial interfaces. 6000W 0-600V 0-120A
Main Features
